HX60R Automatic Hardcover Case Corner Rounding Machine for Book Binding / Children's Board Book / Diary Cover — Inline with Case Making Machine

Name: HX60R Automatic Hardcover Case Corner Rounding Machine for Book Binding Childrens Board Book Diary Cover Inline with Case Making Machine
Brand: HXCP
Price: 36500 USD

Brand Name : HXCP

Model Number : HX60R

Certification : CE

Place of Origin : China

MOQ : 1set

Price : USD 36500 per set

Payment Terms : T/T

Supply Ability : 10 sets/month

Delivery Time : 30 work days

Packaging Details : Stretch Film with Wooden Case

Maximum Case Size : 700×400mm (L×W)

Minimum Case Size : 150×100mm (L×W)

Fastest Speed : 60m/min

Dimensions : 2600×1200mm (L×W)

Power : 2kW

Gas Demand : 900L/min @6bar

Weight : 800kg

Voltage : 400v/3ph

Contact Now

HX60R Automatic Hardcover Case Corner Rounding Machine

HX60R Automatic Hardcover Case Corner Rounding Machine for Book Binding / Children's Board Book / Diary Cover — Inline with Case Making Machine

Description

HX60R Hardcover Case Corner Rounding Machine is connected to the hardcover case making machine, the finished hardcover cases are conveyed into the working area through the conveyor belt, then pressed and formed into round corners by the air cylinders and the heated press, and finally sent out to be stacked in batches with counting on the collecting table, after the corner rounding forming, the edge of the round corner is smooth and mellow. It is used to round corners of book cover, especially for hardcover books.

HX60R Automatic Hardcover Case Corner Rounding Machine for Book Binding / Children's Board Book / Diary Cover — Inline with Case Making Machine

Parameters

Model	HX60R
Maximum Case Size	700×400mm (L×W)
Fastest Speed	60m/min
Minimum Case Size	150×100mm (L×W)
Power	2KW
Weight	800kg
Dimensions	2600×1200mm (L×W)
Gas Demand	900L/min @6bar
Voltage	400v/3ph

Products Show

HX60R Automatic Hardcover Case Corner Rounding Machine for Book Binding / Children's Board Book / Diary Cover — Inline with Case Making Machine

Details
